MOXIN WHEELIE CONTROLLER

The Ultimate Auto Wheelie Controller for High Performance E-Dirt Bikes:
The Moxin Wheelie Controller is a breakthrough upgrade for riders who want maximum power, intelligent control, and effortless wheelies. Designed to push electric dirt bikes beyond their limits, Moxin delivers unmatched voltage capability, true automatic wheelie control, and full plug and play compatibility on the most popular platforms.

Auto Wheelie Mode with Anti Loop Technology:
This is the feature that sets Moxin apart. The controller includes a built in angle sensor that actively monitors front wheel height and automatically holds the bike at a rider selected wheelie angle. The desired angle is adjusted using the handlebar mounted knob, allowing precise control over how aggressive or conservative the wheelie behavior is.

Riders can tune the system to prevent looping entirely, allow controlled wheelies at a fixed balance point, or disable wheelie mode completely for unrestricted riding. This technology allows riders of any skill level to hold smooth, consistent wheelies with minimal throttle input and dramatically increased confidence.

Pre Installed Bike Options:
We offer professional pre installation of the Moxin Wheelie Controller on the Surron Ultra Bee, Surron Light Bee X, and E Ride Pro SS 3.0 for a €59.99 surcharge. Each bike is delivered fully configured, tuned, and ready to ride straight out of the box.

Unmatched Battery Compatibility:
The Moxin controller supports battery systems up to 32s, reaching 134.4 volts fully charged with the 120V controller option. Higher voltage allows the same power to be produced with less current, which reduces heat, increases efficiency, and improves overall range. This makes Moxin ideal for high power builds that demand reliability at extreme performance levels.

Adjustable Power Modes:
Moxin allows you to create and fine tune up to three different power modes. Power delivery, speed limits, and response can be adjusted to suit different riders or riding conditions. This makes it easy to set a reduced power mode for beginners or unleash full power when maximum performance is required.

Advanced Controller Protection:
The Moxin controller includes extensive protection features to safeguard the controller, battery, and motor. Users can configure voltage and temperature limits to prevent overheating and reduce unnecessary wear. These protections help ensure consistent performance and long term reliability even during aggressive riding.

Display Options:
Moxin offers three available screen sizes to match your setup and riding style. A compact 3 inch display keeps things minimal, the 5 inch display offers excellent visibility while riding, and the 7 inch display delivers maximum visibility for riders who want all data front and center.

Real Time Data Monitoring:
The real time data display provides detailed system information that simplifies diagnostics and tuning. Riders can view controller temperature, motor temperature, battery voltage, throttle input voltage, regen brake voltage, RPM, phase current, and many other live parameters. This makes identifying sensor issues or setup problems faster and easier than ever.

IP68 Water and Dust Resistance:
Built for real world riding conditions, the Moxin controller carries an IP68 rating. It is fully protected from dust and waterproof up to 10 meters for 30 minutes, making it suitable for trail riding, wet conditions, and harsh environments.

Self Motor Learning:
Moxin features an intelligent self learning mode that automatically configures the controller to your specific motor. This allows compatibility with a wide range of motors including the stock Surron Light Bee X motor, stock Surron Ultra Bee motor, stock E Ride Pro motor, Talaria Sting R motors, KO motors, QS motors, EBMX XLB and XUB motors, and Sotion motors.

80V Controller Specifications:
The 80V controller operates from 48V to 80V battery systems ranging from 12s to 22s. It delivers a peak phase current of 1100 amps, a rated power of 16 kilowatts, and peak power output of 61.6 kilowatts. Maximum efficiency reaches 96 percent. The controller is IP68 rated, operates from minus 40 degrees Celsius to 75 degrees Celsius, uses field oriented control motor logic, and includes a one year warranty.

120V Controller Specifications:
The 120V controller supports battery systems from 48V to 120V, covering 12s to 32s configurations. It provides a peak phase current of 1000 amps, rated power of 21 kilowatts, and peak power output of 84 kilowatts. Maximum efficiency is 96 percent. The controller is IP68 rated, operates from minus 40 degrees Celsius to 75 degrees Celsius, uses field oriented control motor logic, and includes a one year warranty.

Bike Compatibility:
The Moxin Wheelie Controller installs plug and play on the Surron Light Bee X, Surron Ultra Bee, E Ride Pro SS & SR, Tuttio and Talaria models with no wiring modifications required.
